60 bay nas case 12Gb/s expander backplane for cloud storage
- Backplane12Gb/s expander backplane
- Dimensions437.5mm x 650mm x 265mm (W*D*H)
- MaterialAluminum Alloy,1.0mm SGCC Zinc-Coated Steel
- CertificationAccording to customer request
- Front Ports2*USB3.0
- Power SupplyCRPS
- Brand NameToploong
- Cooling Fan6pcs 12038 hot-swap fans
- Form FactorE-ATX
- TypeRack
- SwitchPower ON/OFF x 1, System reset x 1, UID Switch x 1, USB3.0 x 2
- MotherboardMax support 12''x13''(E-ATX) motherboard
- StyleWith Fan,With Side Panel Window
- HDD Bay60 x 3.5' hot-swap SATA/SAS drive bays+built-in 2x2.5'' drive bays
- ApplicationServer
- HDD Tray2.5''/3.5'' HDD(Anti-EMI)
- Packaging DetailCarton box with PE foam Size
60 bay nas case 12Gb/s expander backplane
for cloud storage S665-60
| Model | S665-60 | |
| Form Factor | 6U Rackmount Server Case with 60 Hot-swappable SATA/SAS Drive Bay, Mini SAS/SATA Connector | |
| Material | Metal material | SGCC |
| Metal thickness | 1.0mm | |
| Panel material | Metal | |
| Handle material | Aluminium | |
| M/B support | EE-ATX(13.68''*13''),E-ATX(12''*13''),CEB(12''*10.5''),ATX(12''*9.6''),micro ATX(9.6''*9.6''),mini-ATX(6.7''*6.7'') | |
| Size | D*W*H(mm) | 437.5*650*265 |
| D*W*H(inch) | 17.2*25.6*10.4 | |
| Drive Bay | 3.5'' HDD(hot-swap) | 60 |
| 2.5'' HDD/SSD(hot-swap) | 2 | |
| Power Supply support | CRPS power supply | |
| Front Panel | Control button | Power ON/OFF x1,System reset x1,UID Switch x1 |
| Indicator | Power ON/OFF x1,HDD x1,NIC x2,UID LED x1,Power Alarm x1,Temperature Alarm x1 | |
| Ports | USB2.0 x2(optional USB3.0) | |
| Expansion | Riser Slot | 7pcs(mid height) |
| Hot-swap Backplane | 12Gb/s Expander backplane | |
| System cooling(optional) | Front | No |
| Middle | 6pcs 12038 hot-swap fans | |
| Rear | No | |
| Net weight | 43.5kg | |
| Gross weight | 45.5kg | |
| Packing size | D*W*H(mm) | 830*590*430 |
| D*W*H(inch) | 32.7*23.2*16.9 | |
| Packing material | Polyfoam with carton box | |
Q1: Can you put my brand name (logo) on these products?
A1: Yes,.We can support OEM/ODM service, the process of customization is following:
1.provide your specific requirement. 2.our design engineer draw the design draft.
3.you confirm the design draft. 4.we start produce it.
Q2: What payment method do you accept?
A2: T/T,Western Union,PayPal.
Q3: What is the Minimum Order Quantity(MOQ)?
A3: We can sell one piece sample for your test.
Q4: What is the lead time of your products?
A4: 3 days for one sample, 15 working days for a large quantity.
Q5: Will it be ok to run the device 24 hrs a day 7 days a week, just like a desktop pc? Will it be overheated?
A5: There's no problem with running the device 24/7. I've done it for about a month and have had no problems. Just set your monitor to sleep when you're not using the computer.
Q6: How does your factory do related quality control?
A6: Quality is top priority. We firstly check the motherboard quality after manufacturing, secondly check the computer before storage in warehouse and thirdly check before shipping out.
Q7: What’s the warranty of motherboard or MINI PC?
A7: Non-artificial damage,1 years warranty; the second year and the third year,
we can repair it free, but we will charge for the parts that need to change.
Q8: If we come to China, can you arrange the visiting to your factory?
A8: We warmly welcome and look forward to your visiting to our factory at any time.
